Portable borehole geological mining drilling rig machine cheap
Product Description
Portable borehole geological mining drilling rig machine is widely used in rocky areas for water wells, blast hole, geothermal air-conditioning wells usages.
Trailer mouted, easy to move. Work with DTH hammer and air compressor can drill very hard rock.
The most compact structure, less space occupied, small and portable type, very suitable for small business or drilling projects.
Certifications
Payment Term
Working Site
FAQ
1. Q: Whether you are a manufacture or trading company?
A: We are a professional manufacturer of drilling equipment and you are welcomed to visit our factory at any time. We have the core technology and keep researching and developing all the time, to provide high quality products and best service.
2. Q: I don't which machine to choose because of there are so many machines.
A: As a professional manufacturer, we provide turn-key solution of drilling machine. If you have any doubt about what type of the machine you need, send an email to us and your question will be solved quickly.
3. Q: I am not familar with a new machine, how to use it?
A: First, the machine is not too complex to make people feel fuzzy. Second, we provide operation manual and DVD to guide you. Then, we also provide Free training in our factory if you were possible to come;
4. Q: How can I change the broken parts if the machine got problems?
A:We provide some wearing parts for you when the first time you purchase goods from us;We also provide wearing parts for your choice.
Contact Information
Any questions about Portable borehole geological mining drilling rig machine, please send E-mail
Product Description
Portable borehole geological mining drilling rig machine is widely used in rocky areas for water wells, blast hole, geothermal air-conditioning wells usages.
Trailer mouted, easy to move. Work with DTH hammer and air compressor can drill very hard rock.
The most compact structure, less space occupied, small and portable type, very suitable for small business or drilling projects.
1. Drilling Depth:150m
2. Drilling Caliber:115-254mm
3. Feeding Stroke:1500mm
4. Power:24kw
Product Parameters
| DF-150S Technical Parameter | |
| Dimension(mm) | 4300×1270×1500 |
| Caliber(mm) | 115~254 |
| Max depth(m) | 150 |
| Walking speed(Km/h) | 0-2 |
| Feeding stroke(mm) | 1500 |
| Grade ability(°) | 30 |
| Work pressure(MPa) | 1.0~2.0 |
| Air consumption(m³/min) | 10~20 |
| Leg cylinder stroke(mm) | 1600 |
| Ground clearance(mm) | 200 |
| Diameter of the drill pipe(mm) | 76/89/102 |
| Axial pressure(N) | 28000 |
| Lifting force(N) | 58000 |
| Hoist(N) | 15000 |
| Rotary torque(Nm) | 3600 |
| Power(Kw) | 24 |
| Impact frequency | 840/1500 |
| Apply for rock hardness(f) | 6~20 |
