Product Information
TSJ series Drilling Rigs are mechanical transmission, turnplate rotation Drilling Rig, characterized by low center of gravity, smooth transmission of motion, reliable operation and perfect sealing, the structure of the drill is reasonable arranged and compact, and easy to maintain and repair etc, it adopts hydraulic oil cylinder to mechanical screw out drilling pipes, this will save labout and ensure good drilling holes, it can also adopt other way to mechanical screw out drilling pipes, such as the technique used in petroleum explorating, that is to use the cat head. It is mainly used for drilling underground water resource, shallow petroleum, natural gas, coal gas and geothermal, also for geological drilling, well drilling and other engineering drilling.
Company Information
TSJ series Drilling Rigs are mechanical transmission, turnplate rotation Drilling Rig, characterized by low center of gravity, smooth transmission of motion, reliable operation and perfect sealing, the structure of the drill is reasonable arranged and compact, and easy to maintain and repair etc, it adopts hydraulic oil cylinder to mechanical screw out drilling pipes, this will save labout and ensure good drilling holes, it can also adopt other way to mechanical screw out drilling pipes, such as the technique used in petroleum explorating, that is to use the cat head. It is mainly used for drilling underground water resource, shallow petroleum, natural gas, coal gas and geothermal, also for geological drilling, well drilling and other engineering drilling.
| Drilling Depth(m) | Φ89 Drill pipe | Φ114 Drill pipe |
| 3000 | 2500 | |
| Opening Diameter of Rotary Table(mm) | φ445 | |
| RPM of Rotary Table(r/min) | (CW CCW)43, 63, 93, 156 | |
| Max. Norminal torque out of Turnplate(KN·m) | 34 | |
| Wire Diameter(φmm) | 24.5 | |
| Hoisting Capacity of Windlass(KN) | 115 | |
| Lift Speed of the Winch(m/s) | 1.1, 2.4, 4.1 | |
| Input Speed of Clutching(r/min) | 901 | |
| Diesel Engine Model and power(KW) | 12V135N-SM 194KW | |
| Rotary Speed(r/min) | 1500 | |
| Electronic Power Model and power(KW) | Y280M-4 × 2set 90KW × 2set | |
| Travelling System | 5×6 | |
| Weight(t) | 10.54 | |
| Dimensions(L*W*H)(mm) | 5722×2565×1750 | |
