Tysim Rotary Pile Driver, Drilling Machine, Rotary Pile Driver, Small Pile Driver, Excavator Chassis Max. Drilling Depth 60m Kr220c Drilling Pile Driver

Technical SpecificationTypeKR220CTorque220 KN.mMax. diameter1800/2000 mmMax. drilling depth51 m(Lock)/ 64 m(Friction kelly bar)Speed of rotation5~26 rpmMax. crowd pressure210 kNMax. crowd pull220 kNMain winch line pull230 kNMain winch line speed60m/minAuxiliary winch line pull90 kNAuxiliary winch line speed60 m/minStroke(crowd s

Featured Products

Tysim Rotary Piling Rig, Drill Machine, Rotary Pile Machine, Small Pile Rig, Excavator Chassis Max. Drilling Depth 60m Kr220c Bore Piling Rig Machine
Technical Specification
TypeKR220C
Torque220 KN.m
Max. diameter1800/2000 mm
Max. drilling depth51 m(Lock)/ 64 m(Friction kelly bar)
Speed of rotation5~26 rpm
Max. crowd pressure210 kN
Max. crowd pull220 kN
Main winch line pull230 kN
Main winch line speed60m/min
Auxiliary winch line pull90 kN
Auxiliary winch line speed60 m/min
Stroke(crowd system)5000mm
Mast inclination(lateral)±5°
Mast inclination(forward)
Max. operating pressure35 MPa
Pilot pressure4 MPa
Travel speed2km/h
Traction force420 kN
Operating height21236 mm
Operating width4300mm
Transport height3323 mm
Transport width3000 mm
Transport length15260mm
Overall weight64 t
Tysim Rotary Piling Rig, Drill Machine, Rotary Pile Machine, Small Pile Rig, Excavator Chassis Max. Drilling Depth 60m Kr220c Bore Piling Rig Machine

Tysim Rotary Piling Rig, Drill Machine, Rotary Pile Machine, Small Pile Rig, Excavator Chassis Max. Drilling Depth 60m Kr220c Bore Piling Rig Machine

Tysim Rotary Piling Rig, Drill Machine, Rotary Pile Machine, Small Pile Rig, Excavator Chassis Max. Drilling Depth 60m Kr220c Bore Piling Rig Machine

Tysim Rotary Piling Rig, Drill Machine, Rotary Pile Machine, Small Pile Rig, Excavator Chassis Max. Drilling Depth 60m Kr220c Bore Piling Rig MachineTysim Rotary Piling Rig, Drill Machine, Rotary Pile Machine, Small Pile Rig, Excavator Chassis Max. Drilling Depth 60m Kr220c Bore Piling Rig Machine
Tysim Rotary Piling Rig, Drill Machine, Rotary Pile Machine, Small Pile Rig, Excavator Chassis Max. Drilling Depth 60m Kr220c Bore Piling Rig Machine
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
